NVIDIA2021
GeForce RTX 3060
GeForce 30
AmpereGA1068 nm
Memory12 GB GDDR6
Boost clock1,777 MHz
Board power170W
As an Amazon Associate we earn from qualifying purchases
Release context
GeForce RTX 3060 at a glance
GeForce RTX 3060 is a 2021 graphics processor from the GeForce 30 family. Its catalog specifications include the Ampere architecture, 12 GB of GDDR6, a boost clock up to 1,777 MHz, a 170W board power rating.
Compare with Another GPU
Select a graphics card to see a side-by-side comparison with the GeForce RTX 3060.
Boost Clock
1,777 MHz
VRAM
12 GB
TDP
170W
Memory Bandwidth
360 GB/s
Shading Units
3584
Memory Bus
192 bit
Performance Specs
Base Clock
1,320 MHzBoost Clock
1,777 MHzShading Units / Stream Processors
3584Texture Units
112Render Output Units
48Memory Specs
VRAM Size
12 GBMemory Type
GDDR6Memory Bus Width
192 bitMemory Clock
1,875 MHzMemory Bandwidth
360 GB/sArchitecture & Manufacturing
Architecture
AmpereCode Name
GA106Process Node
8 nmDie Size
276 mm²Transistors
12,000MInterface & Power
Bus Interface
PCIe 4.0 x16TDP (Thermal Design Power)
170WDisplay & Dimensions
Pricing & Info
Launch Date
January 12, 2021Generation
GeForce 30API Support
DirectX
DirectX 12OpenGL
OpenGL 4.6Vulkan
Vulkan 1.4CUDA
CUDA 8.6OpenCL
OpenCL 3 Suggested matchups
