NVIDIA2023
GeForce RTX 4060
GeForce 40
Ada LovelaceAD1075 nm
Memory8 GB GDDR6
Boost clock2,460 MHz
Board power115W
As an Amazon Associate we earn from qualifying purchases
Release context
GeForce RTX 4060 at a glance
GeForce RTX 4060 is a 2023 graphics processor from the GeForce 40 family. Its catalog specifications include the Ada Lovelace architecture, 8 GB of GDDR6, a boost clock up to 2,460 MHz, a 115W board power rating.
Compare with Another GPU
Select a graphics card to see a side-by-side comparison with the GeForce RTX 4060.
Boost Clock
2,460 MHz
VRAM
8 GB
TDP
115W
Memory Bandwidth
272 GB/s
Shading Units
3072
Memory Bus
128 bit
Performance Specs
Base Clock
1,830 MHzBoost Clock
2,460 MHzShading Units / Stream Processors
3072Texture Units
96Render Output Units
48Memory Specs
VRAM Size
8 GBMemory Type
GDDR6Memory Bus Width
128 bitMemory Clock
2,125 MHzMemory Bandwidth
272 GB/sArchitecture & Manufacturing
Architecture
Ada LovelaceCode Name
AD107Process Node
5 nmDie Size
159 mm²Transistors
18,900MInterface & Power
Bus Interface
PCIe 4.0 x8TDP (Thermal Design Power)
115WDisplay & Dimensions
Pricing & Info
Launch Date
May 18, 2023Generation
GeForce 40API Support
DirectX
DirectX 12OpenGL
OpenGL 4.6Vulkan
Vulkan 1.4CUDA
CUDA 8.9OpenCL
